elmeg IP630
bintec elmegConnections
Connections
1 Expansion module with additional function keys
2LAN (PoE)
3
PC; a PC can also be connected to the telephone instead of to the local network, the
telephone establishes the network connection
4 Receiver
5 Headset with RJ11 plug
6 EHS headset (Electronic Hook Switch)
7Power adapter
8USB
1 2 3 4 5 6 7
8
EHS
