elmeg IP630
bintec elmeg Status of the telephone
Restore Device Settings from PC
¤ Click Browse select the stored back-up file from the file system . . . the file is displayed
click . . . the file is loaded; a message indicates whether the loading process has been suc-
cessful or not confirm the message with OK
Deleting unwanted back-up files: click
Rebooting or resetting the system
¤ Settings System Reboot and Reset
Once this has been completed, the login screen is displayed again, the telephone is in idle
status.
Status of the telephone
The Status menu contains information about the status of the telephone.
Device
The page shows general information about the telephone, such as the IP address, the current
status of the firmware and the time and date settings.
¤ Status Device
Connections
The page shows information about the VoIP connections configured for the telephone.
¤ Status Connections . . . name and status are shown for each connection
The Default send connection is marked with .
Changing the standard send connection: page 33
Storage Allocation
The page shows the memory space occupied by the internal memory and how much is still
available (in percent). Files are stored in the internal memory, for example.
¤ Status Storage Allocation
Restart the system:
¤ Click Reboot system now confirm prompt with Ye s . . . the
telephone is rebooted and temporarily not ready for operation.
Reset the system:
¤ Reset to factory settings Confirm prompt with Ye s . . . all personal
settings, lists and directory entries are deleted, passwords are reset.
Resetting the device using the display menu: page 29
Status Registered VoIP connection available.
Not registered Currently there is no VoIP connection assigned. The telephone
cannot be used.
¤ Please contact the administrator
