ET8/480, ET8/480S and ET8/480PT - TECHNICAL MANUAL - 5
4. TECHNICAL SPECIFICATIONS
Model ET8/480 (ET8/480S).
Level of performance 2nd with device against removal mounted at installer’s discretion.
Degree of protection IP3X.
Mains supply 230V +/- 10% 50Hz via safety transformer fixed to the base of the
housing; 12V 15 Ah max. back up battery.
Battery recharge voltage 13.8V (13.4V / 14.4V).
Nominal output voltage 13V .
Normal functioning Between 9V and 15V .
Nominal current supplied 2.5A.
Limitation in current 2.7A.
Residual ripple 40 mV .
VOUT stabilisation +/- 2% at charge change.
Maximum consumption from mains 300 mA.
Battery recharge current 1.5A for 15Ah battery.
Maximum current on charge 700 mA.
Consumption @ 12V(ET8/480s with a
NADIR keyboard connected)
with control unit enabled:
with control unit disabled:
with control unit in alarm status:
300 mA (340 mA).
260 mA (300 mA).
360 mA (400 mA).
Consumption of other accessories
possibly connected:
NADIR keyboard: Increase of 55 mA with system disabled, 90 mA with system enabled,
180 mA max.
AURORA keyboard: Increase of 50 mA with system disabled, 80 mA with system enabled,
107 mA max.
AURORA/SC keyboard Increase of 31 mA with system disabled, 53 mA with system enabled,
87 mA max.
ZENITH Key point: Increase of 40 mA with system disabled, 70 mA with system enabled.
Readers I6 or I7: Increase of 30 mA.
SK/SINT voice synthesis card: Increase of 25 mA in stand-by mode and 40 mA in alarm mode.
CP8/TR two input/output type
transponders: 43 mA in stand-by mode and 73 mA with relays in pick-up mode
CP8/TRS two-input type transponders: 43 mA in stand-by mode.
CP8/TR8B eight-input type
transponders: 50 mA in stand-by mode without outputs connected.
CP8/TR8 eight-input type transponders: 50 mA in stand-by mode without outputs connected.
CP8/TR30 concentrator: 110 mA with just one TR9000 module connected, 140 mA with 30 TR9000
connected.
Board with RS232 double serial 80 mA.
Operating temperature - Humidity: +5 / +40 °C - 93% humidity.
Batteries which can be connected: 12V max. 15Ah.
Dimensions of casing: L 480 - H 305 - B 140 mm ( ET8/480PT L 525 - H 380 - B 280 mm).
Weight: 4 Kg ( 15 Kg for ET8/480PT)
Equipment: 33 1500 Ohm input balancing resistors, 2 termination resistors for 680 Ohm
serial line, small bag with 4 5x54 threading screws and 4 S8 wedge, micro-
switch against housing opening and removing (Against house-breaking kit
with inertial sensor and analysis board for ET8/480PT), rubber-sheathed
cable with connector for remote reader (not included as part of ET8/480S
equipment), technical and programming manual, Cd programming with
PDF manuals.
NOTE:
The transponders must be connected directly to the specific terminal board of the control unit indicated as A and B
and may be powered by the mains supply terminals of the keyboard. They must be connected according to this
manual’s diagrams by using a screened cable for theft and flame prevention with a minimum section of 0.75 mm2 for
short lengths and a minimum section of 1mm2 or greater for long lengths. Maximum connection distance between
control unit and the last transponder is 1,000 metres with transponders evenly distributed. For the system’s autonomy
and powered load’s optimization, it is reccomended the use of remote mains supply boxes such as model C11K,
especially when the control unit is used with several keyboards, transponders and volumetric sensors.
