51
Images on the SD
card/USB flash drive
are not displayed.
・Remove the SD card/USB flash drive, wait for a few seconds, and insert again.
（⇒P.15）
・”Freeze” function is used. Press the Freeze button [ ] on the operating panel or
[ ] on the remote control to restart the live image feed.（⇒P.13、17）
Not possible to operate
with the Remote
control.
・The remaining battery level of the remote control is low. Replace the battery with a
new one.
・Wrong remote control is used. Use the supplied remote control.（⇒P.17）
After inserting the SD
card/USB flash drive,
operations cannot be
performed.
The SD card/USB flash drive is not being read correctly. Use the SD card/USB flash
drive after formatting it twice as described below. First, format the card using a PC.
Then, format the card using the PX-10E/30E.（⇒P.29）
The touchscreen does
not work properly.
・Check that the touch points on the touchscreen are pressed correctly.
（⇒P.23）
No audio from the
external microphone.
・The audio volume is too low. Go to the System Setting and adjust the volume (⇒
P.28), or adjust the volume of the external microphone.
・Go to the System Setting and check that " External mic” is selected in the “Sound
switch”. （⇒P.28）
The network function
does not work.
・Check the network configuration of the PX-30E and the PC to be connected to the
PX-30E.
The LAN cable cannot
be connected.
・The LAN port (RJ45) is located on the rear panel of PX-30E.
・Check that the connector of the LAN cable is properly connected to the LAN port.
The LAN link LED does
not light up.
・Power is not supplied to the PX-30E or to the device connected to the PX-30E.
Check that the cable is connected firmly, and then turn on the power.
・The cable is disconnected. Check the connection between the cable terminals.
・Wrong cable is used. When a device to be connected to the PX-30E is a PC, “LAN
cross cable” is used, and when it is a hub or router, “straight cable” is used.
Cannot connect to the
PX-30E from the client.
・The IP address of the PX-30E has not been designated. Designate the IP address
set in the PX-30E.
・The IP address of the client is not compatible with the network of the PX-30E. To
establish the connection from the client to the PX-30E, the network address should
be same between the client and the PX-30E.
Default setting of the PX-30E：DHCP
The set time will be
reset automatically.
・The clock setting will be reset automatically after a long period of non-operation.
Then you will need to perform the clock setting again.
※Only for the version equipped with the Time setting function.
Any changes to the
settings will not be
saved.
・Perform the initialization from the System Setting menu and retry.
If the power is turned off immediately after changing the settings, the changes may
not be reflected.
Wait at least 2 seconds when turning off the power after changing the settings.
No image is displayed
from the USB port.
・No image will be output from the USB port during still image playback, video
playback, video recording, or external input (HDMI-1, HDMI-2, RGB).
When outputting the image from the USB port, switch to the camera image from the
Select image menu.
The UVC image is
upside down.
・Check that the graphics driver and other device drivers on your computer are
updated. The latest device drivers are available from the computer manufacturer.
To Next Page
