Elmo TT-02U User Manual

67 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

PART

NAMES AND

FUNCTIONS

SETTING

UP

STORING

OPERATION

PROCEDURE

VARIOUS

FUNCTIONS AND

OPERATIONS

TROUBLESHOOTING

SPECIFICATIONS

English

P

1~

P

33

Teacher’s Tool

INSTRUCTION MANUAL

Please read this instruction manual carefully

before using this product and keep it for

future reference.

Table of Contents

Questions and Answers:

M
Michael MullinsJul 26, 2025
Why is no image displayed on my Elmo TT-02U Document Camera?
- F
  Fernando MoranJul 26, 2025
  If your Elmo Document Camera isn't displaying an image, several things could be the cause. First, check all cable connections to ensure they are secure. Verify that the AC adapter is properly connected to both the wall outlet and the document camera's power supply socket. Also, ensure the power supply is turned ON (the green light should be lit). If the zoom is set to the TELE side, adjust the zoom settings. If you have just turned the device off and then immediately back on, wait a few seconds before turning it back on again. Finally, ensure that the dip switch is set to the correct image output (RGB/VIDEO).
H
Heidi KruegerAug 9, 2025
What to do if the image on my Elmo TT-02U is out of focus?
- J
  Jennifer MillerAug 10, 2025
  If the image on your Elmo Document Camera is out of focus, try these solutions: First, ensure that the object or document isn't too close to the lens; move it further away. If you've been using a wide-angle (WIDE) zoom setting, try focusing at the maximum TELE side limit. If autofocus isn't working, you can manually focus the image.

Elmo TT-02U Specifications

General

Camera Type	Digital
Maximum Resolution	1920 x 1080
Frame Rate	30 fps
Zoom	8x Digital Zoom
Compatibility	Windows, Mac
Weight	0.6 kg (1.3 lbs)
Focus	Auto Focus
Output Resolution	1920 x 1080, 1280 x 720, 640 x 480
USB Interface	USB 2.0
Microphone Input	Yes
Built-in Illumination	LED
Image Sensor	CMOS
Connectivity	USB
Effective Pixels	2MP
Video Output	USB
Power Supply	USB bus power

Summary

1 PART NAMES AND FUNCTIONS

Name of Each Part

Identifies and illustrates all physical parts of the document camera unit.

Functions

Details the purpose and operation of each control button on the unit.

Rear Panel

Describes the various input and output terminals on the rear of the unit.

OSD (On Screen Display)

2 SETTING UP

Setting Up

Guides the user through the physical setup and connection of the document camera.

Connecting of AC adapter and Video cable

Provides instructions on connecting power and video cables to the unit.

4 OPERATION PROCEDURE

Presentation using printed materials, etc.

Explains how to set up and use the camera for presenting documents and objects.

Presentation using printed materials, etc. (Using the stage)

Presentation using the supplied software with the USB-connected PC

Presentation using a Microscope

6 TROUBLE SHOOTING

Symptoms and Confirmation

Provides a guide to identify and resolve common issues encountered with the product.

7 SPECIFICATIONS

General

Lists the general technical specifications for the document camera.

Main Camera

Details the specific technical specifications for the camera module itself.
