22
OPERATION
PROCEDURE
Shooting a 3-D object
By adjusting angle of the camera column and the camera head, a 3-D object can be shot from
the side.
Adjust
Adjust
Adjust
■ Setting the main unit
Connect the main unit to a projector or a PC monitor.
Then turn the power switch of the main unit ON. Adjust angle of the camera column and the
camera head as shown in the above figure to shoot a 3-D object.
■ Adjusting the size
Adjust the position of the object with the zoom dial so that the objective part fits the screen
size.
■ Adjusting the focus
Press the [AF] button to focus the camera. In a case when the object can not be brought
into focus with the [AF] button, adjust focus with the manual focus by selecting [Focus] in
the OSD menu.
P. 2 5
■ Adjusting the brightness
Press the [BRIGHTNESS •
] and [BRIGHTNESS •
] buttons on the main unit to
adjust image brightness.
P.27
Note
• The focus can be achieved from 50mm to ∞.
To Next Page
