ELNA 320 - Feed Balance

14
Adjusting Feed Balance
The forward feeding (A) and backward feeding (B) should be equal when sewing stretch stitch
pattern.
<TO ADJUST>
1 Select the straight stretch stitch ( ) and set the stitch length dial at S.S.
2 Place a piece of paper under the foot. Turn the handwheel to check the needle marks.
3 If the forward feeding (A) is longer than backward feeding (B), turn the adjusting screw in the
direction (C).
4 If the forward feeding (A) is shorter than backward feeding (B), turn the adjusting screw in
the direction (D).
A
A
B
1
2
3
A
A
1
2
3
B
A
A
1
2
3B
A
B
A
B
A
B
(D) (C)
Adjusting screw
