ELNA 320 - Rear Cover

4
Rear cover
(C)
(B)
(D)
Setscrew (A)
(B)
Presser lifter
(1)
(2)
(3)
Service access (4)
Rear cover
<TO REMOVE>
1 Remove the face cover and front cover (see page 1~3).
2 Remove setscrews (A), (B), (C) and (D).
Lower the presser foot.
Remove the rear cover from the part (1), (2) to (3) in order.
<TO ATTACH>
3 Mount the rear cover in reverse procedure of the removing.
