17
Mechanical Adjustment
TO CHECK:
If the material is feed forward or backward when sewing bartack on buttonhole, make an
adjustment as follows:
ADJUSTMENT PROCEDURE:
1. Set the pattern selector control at " " and the stitch length control at "4".
2. Remove the front cover. (See page 5.)
3. Place a piece of paper under the foot and turn the handwheel.
If the paper is fed forward, turn the adjusting screw in the direction of (C).
If the paper is fed backward, turn the adjusting screw in the direction of (D).
4. Attach the front cover.
FORWARD FEEDING
BACKWARD FEEDING
(D) (C)
ADJUSTING SCREW
