ELNA 320 - Front Cover

3
Service Access (3)
FRONT COVER
<TO REMOVE>
1 Remove the face cover and the base cover (see page 1, 2).
2 Remove dials (A), (B).
3 Loosen setscrews (A), (B), (C).
4 Unhook the tabs and remove the front cover.
<TO ATTACH>
5 Reverse the procedure above.
Dial (A)
Dial (B)
Tab
Setscrew(A)
(B)
Front cover
Tab
Setscrew (C)
Tab
