Service Access (2)
BASE COVER
<TO REMOVE>
1 Loosen setscrews.
2. Take the base cover out.
<TO ATTACH>
3 Follow the above procedure in reverse.
Setscrew
Setscrew
Setscrew
Base cover
Setscrew
Setscrew
Setscrew
Feed dog drop le-
ver
