1.4.1.1 Red
1. ”Up” & “Down” Icons will be “+”&”-“ at this
menu.
2. Show the Red value and gauge.
Yes
1.4.1.2 Green
1. ”Up” & “Down” Icons will be “+”&”-“ at this
menu.
2. Show the Green value and gauge.
Yes
1.4.1.3 Blue
1. ”Up” & “Down” Icons will be “+”&”-“ at this
menu.
2. Show the Blue value and gauge.
Yes
1.5 OSD Menu
1. Show OSD Timeout value on this menu. Yes but
no
rotation
