1. Product Overview
1.1. Specification overview
Model Name ET1517L ET1717L
LCD Size 15"
17”
LCD Vendor CMI / AUO
CMI / AUO
Panel Model No G150XGE-L04 / G150XG03 V5
M170EGE-L20 / G170EG01-V1
Active Area (mm) 304.128(H) x 228.096(V)
337.920 (H)x 270.336(V)
Resolution XGA 1024 x 768 (pixels)
XGA 1280 x 1024 (pixels)
Aspect Ratio 4:3
5:4
Brightness (typ)/(min) 250 nits (typ.)/200 nits (min)
300 nits (typ.)/250 nits (min)
Contrast Ratio (typ.) 700:1 (typ.) 800:1 (typ.)
Response Time (ms) 8ms (typ.)/ 16max 5ms (typ.)/ 10max
Pixel Pitch 0.297mm 0.264mm
Viewing Angle 160 degree (H) / 140 degree (V) 170 degree (H) / 160 degree (V)
Panel
Panel Bit (8 or 10) 8bit (16.2M) 8bit (16.7M)
Platform
Solution
Scalar Realtek 2281W Realtek 2281W
Voltage 100 V ~ 240 V, 50 Hz / 60 Hz 100 V ~ 240 V, 50 Hz / 60 Hz
Maximun (Watt) <10W <21W
Standby (Watt) <1.1W <1.1W
Power
Power Off (Watt) <1.0W <1.0W
Operation Temp (dC) 0°C ~ 40°C 0°C ~ 40°C
Storage Temp (dC) -20°C ~ 60°C -20°C ~ 60°C
Storage Humidity 10% ~ 90% RH Non-Condensing 10% ~ 90% RH Non-Condensing
Operating Humidity 20% ~80% RH Non-Condensing 20% ~80% RH Non-Condensing
Operating Altitude 0 ~ 10,000 feet[ 3048m] 0 ~ 10,000 feet[ 3048m]
Environment
Non-operating 0 ~ 35,000 feet[ 10,668m] 0 ~ 35,000 feet[ 10,668m]
