Service Manual: ET1517L, ET1717L
ES600904 Rev B, Page 5 of 44
1.2. Interface Functions
1.2.1 VGA
The monitor will be able to display analog RGB component video when inputted to the DE-15
VGA connector. It shall comply with the VESA DDC/CI standard.
1.2.2 DVI
No DVI connector for this product.
1.2.3 LED indicator
Condition
(Applies to Monitor or Monitor with
Computer Module)
LED status
OFF OFF
SLEEP PULSING
ON ON
1.3. Software Specification
1.3.1 Compliant Timing
ET1515L ET1717L
Preset Video Modes
(input video modes which won’t
require user adjustments to
image)(refer to SW600637 for
detailed timing parameters)
640x480 60Hz,75Hz
720x400 70Hz
800x600 56Hz,60Hz,75Hz
1024x768 60Hz,75Hz
640x480 60Hz,75Hz
720x400 70Hz
800x600 56Hz,60Hz,75Hz
1024x768 60Hz,75Hz
1280x1024 60Hz,75Hz
Input Video Horizontal Frequency
(outside these ranges, monitor will
permanently display an Out Of Range
message)
31.5 – 80 KHz 31.5 – 80 KHz
Input Video Vertical Frequency
(outside these ranges, monitor will
permanently display an Out Of Range
message)
56 – 75 Hz 56 – 75 Hz
US054952 - 2012-09-28T00:54:02Z
