3. Level 2 Disassembly /Assembly Circuit Board and Standard Parts
Replacement
3.1. Parts list
ET1517L:
Service Manual: ET1517L, ET1717L
ES600904 Rev B, Page 34 of 44
NO.
ELO P/N Qisda P/N Qisda Description
1 E164518 5F.MU5VP.011 LCDM15 G150XG03-V5 AUO P/G
2 E120875 5F.MM5VP.001 LCDM 15 G150XGE-L04 P E120875
3 E516564 TY.5F900.002 TOUCH CCREEN AT 1517 E516564
4 E892455 TY.5F900.003 TOUCH SCREEN IT 1517 E892455
5 CS.5J1US.001 PACK AD BD 15-AUO EP15TF4
6 CS.5J1US.011 PACK AD BD 15-CMI EP15TF4
7 5E.1UT10.001 PCBA KEYPAD BD EP17TF1
8 E329179 EM.5D900.01R PCBA CTR221800ATRSU00R E329179
9 D68054-000 EM.5D900.005 PCACTR270100ITRSU00RD68054-000
10 3J.1US02.001 BEZEL AT AUO ABS GY EP15TF4
11 3J.1US02.011 BEZEL AT AUO ABS WH EP15TF4
12 3J.1US01.001 BEZEL IT AUO ABS GY EP15TF4
13 3J.1US03.001 CASE BACK ABS BLACK EP15TF4
14 3J.1US03.011 CASE BACK ABS WH EP15TF4
15 3J.1US04.001 CASE MSR BC ABS BLACK EP15TF4
16 3J.1US04.011 CASE MSR BC ABS WH EP15TF4
17 3J.1US05.001 CASE F STAND ABS EP15TF4
18 3J.1US05.011 CASE F STAND ABS WH EP15TF4
19 3J.1US06.001 CASE BACK STAND ABS EP15TF4
20 3J.1US06.011 CASE BACK STAND ABS WH EP15TF4
21 3J.1US07.001 CASE VESA STAND ABS EP15TF4
22 3J.1US07.011 CASE VESA STAND ABS WH EP15TF4
23 3J.1US08.001 CASE BASE STAND ABS EP15TF4
24 3J.1US08.011 CASE BASE STAND ABS WH EP15TF4
25 4B.1US01.001 KEY PAD OSD ABS EP15TF4
26 4B.1US01.011 KEY PAD OSD ABS WH EP15TF4
27 4B.1US02.001 LIGHT PIPE OSD PMMA EP15TF4
28 4G.1US05.001 SPONGE H EP15TF4
29 4G.1US06.001 SPONGE V EP15TF4
30 5K.1US04.001 WIRE LVDS 20/30P 1571 150MM
