ET1717L:
Service Manual: ET1517L, ET1717L
ES600904 Rev B, Page 36 of 44
NO.
ELO P/N Qisda P/N Qisda Description
1 E149399 5F.MU7VP.011 LCDM17 G170EG01-V1 AUO
2 E230053 5F.MM7VP.011 LCDM 17 M170EGE-L20 P
3 E086819 TY.5F900.004 TOUCH SCREEN AT 1717 E086819
4 E872607 TY.5F900.005 TOUCH SCREEN IT 1717 E872607
5 CS.5J1UT.001 PACK AD BD 17-AUO EP17TF1
6 CS.5J1UT.011 PACK AD BD 17-CMI EP17TF1
7 5E.1UT10.001 PCBA KEYPAD BD EP17TF1
8 5E.1UT42.001 PCBA DC/DC BD EP17TF1
9 E329179 EM.5D900.01R PCBA CTR221800ATRSU00R E329179
10 D68054-000 EM.5D900.005 PCACTR270100ITRSU00RD68054-000
11 3J.1UT01.001 BEZEL IT AUO ABS GY EP17TF1
12 3J.1UT02.001 BEZEL AT AUO ABS GY EP17TF1
13 3J.1UT02.011 BEZEL AT AUO ABS WH EP17TF1
14 3J.1UT09.001 BEZEL IT CMI ABS GY EP17TF1
15 3J.1UT10.001 BEZEL AT CMI ABS GY EP17TF1
16 3J.1UT10.011 BEZEL AT CMI ABS WH EP17TF1
17 3J.1UT03.001 CASE BACK ABS EP17TF1
18 3J.1UT03.011 CASE BACK ABS WH EP17TF1
19 3J.1UT08.001 CASE BC MSR DOOR ABS EP17TF1
20 3J.1UT08.011 CASE BC MSR DOOR WH EP17TF1
21 3J.1UT04.001 CASE FRONT STAND ABS EP17TF1
22 3J.1UT04.011 CASE F STAND ABS WH EP17TF1
23 3J.1UT05.001 CASE BACK STAND ABS EP17TF1
24 3J.1UT05.011 CASE BACK STAND ABS WH EP17TF1
25 3J.1UT06.001 CASE VESA STAND ABS EP17TF1
26 3J.1UT06.011 CASE VESA STAND ABS WH EP17TF1
27 3J.1UT07.001 CASE BASE STAND ABS EP17TF1
28 3J.1UT07.011 CASE BASE STAND ABS WH EP17TF1
29 4B.1US01.001 KEY PAD OSD ABS EP15TF4
30 4B.1US01.011 KEY PAD OSD ABS WH EP15TF4
31 4B.1US02.001 LIGHT PIPE OSD PMMA EP15TF4
32 4G.1UT03.001 SEAL DUST H EP17TF1
33 4G.1UT04.001 SEAL DUST V EP17TF1
34 5K.1UT04.001 WIRE LVDS 30/30P 1571 150MM
35 5K.1US01.001 WIRE 5/5P 1571#28 140MM
36 5K.1US03.001 WIRE 6/20P 1061#28 90MM TOUCH
