2.19 ALARM SIGNALS
The remote will give alert beep sounds and the display will indicate the
alarm activation reason. While siren sounds the remote display will
indicate flashing icon corresponding to the triggered zone.
If any of security sensors is triggered in the
guard mode, this will automatically activate
alarm signals: siren sounds and light flashes.
Icon on display Alarm cycle duration
20 sec sound and light signals right leſt
3sound signals light signals right leſt
1 level of shock sensor
2 level of shock sensor
Tilt sensor
30 sec sound and 30sec light signals right leſt
3rd stage 30 sec sound and 30sec light signals right leſt
Ignition
Power battery loss
30 sec sound and 30sec light signals right leſt
Perimeter sensor
30 sec sound and 30sec light signals right leſt
The LCD transmitter will keep the triggers icon
flashing until the button 2 is pressed.
