Long interruptions events are counted within observation window of 1 week.
Total events (N) allowed is: 1.
Temporary Overvoltage OK/FAIL: Over-voltage ev ents ar e ch aracterized
with R MS v oltage h igher than 1 0.0% ab ove N ominal ( event d eactivate on
8.0%). Minimum over-voltage event duration is 10 ms., events ar e counted
per all p hases combined within o bservation window o f 1 week. No specific
events count limitation is defined.
Flicker Severity OK/FAIL: Flicker s everity is ev aluated w ithin observation
window of 1 week. During interruption Flicker interval is discarded. During
DIPS o r O ver v oltage Fli cker I nterval i s d iscarded. P lt ( 2 h ours) m ust b e
equal or under 1.0 during 95.0% of observation time.
Harmonic Voltage OK/FAIL: Harmonics evaluated at in tervals o f 10 min.
within o bservation w indow o f 1 w eek. E valuation at i ntervals i n w hich
voltage i s i nside n ominal bou ndary of [+15.0%,-15.0%]. Discarding I ntervals
with V OLT-INT. Discarding I ntervals with DIPS o r OV ER-VOLT. I ndividual
Harmonics ar e l imited a ccording t o t he f ollowing t able: H2<=2.0%,
H3<=5.0%, H4< =1.0%, H5< =6.0%, H6< =0.5%, H7< =5.0%, H8< =0.5%, H9< =1.5%,
H10<=0.5%, H 11<=3.5%, H12 <=0.5%, H 13<=3.0%, . .. T HD limit i s s et 8. 0%
(N2). THD and Harmonics limits shall be kept at least 95.0% of time.
Supply Voltage Unbalance OK/FAIL: Voltage unbalance is ev aluated at
intervals of 10 min. within observation window of 1 week. Evaluation is only
at intervals in which voltage is inside nominal boundary of [+15.0%,-15.0%].
Unbalance limit N 1 is set t o 2 .00% an d must b e kept 9 5.0% o f o bservation
time. Intervals with voltage interruption are discarded. Intervals with DIPS
or Over voltage are discarded.
COMPLIANCE SUMMARY SECTION
The Compliance Type is co nfigured w hen s etting your I nstrument i n PQ
Compliance Configuration.
Running Status means w hether o r no t t he G4K’s P ower Qua lity e ngine is
evaluating the power quality according to the Configured PQ Compliance.
The Embedded Report field further indicates a type of report that is auto-
generated internally in t he device's f ile s ystem. M ost compliance t ypes do
not generate any specific report, & therefore, the report type will be None.
However, CREG type of compliance (used in Colombia) also auto-generates a
specific format of Report Files as defined by the local regulator.
The Evaluation Status field provides an overall status of PASS or FAIL of the
entire compliance. Anytime the evaluation period is not complete (typically
required is a 1 w eek o bservation), t he s tatus w ill b e N/A (Not A vailable),
otherwise PASS will be indicated as OK.
