The Start Time field sh ows t he la st time t he compliance en gine was
restarted. T he e ntire s tate & o bservation w indow h istory is s tored o n t he
internal non-volatile memory, so even after powering down; the Engine will
continue it s ev aluation & m aintain all i ndications. ( Start t ime r emains
unchanged after device powered up.)
The Window Time On/Off fields s pecify h ow m uch aggregated t ime is
already in the o bservation w indow. ON refers t o t he ag gregated w indow
time the d evice was p owered on & OFF refers t o the a mount of w indow
time the device p ower w as o ff. T he f ormat pr esented i s [D ays: H ours:
Minutes: Seconds]. Ideally the OFF time is all zeroes & the ON time is 7 days
(which is t he t ypical f ull o bservation p eriod in m ost o f t he c ompliance
types). Once the observation window reaches 7 days, it will start to slide in
steps o f 2 h ours. S liding m eans t he in formation f rom the o ldest 2 h ours i s
being dr opped, w here a n ew u p-to-date 2 -hour interval is b eing u sed f or
calculations.
The Measurement Flag field in dicates w hether t here is a p ower q uality
event such as a DIP/SWELL or INTERRUPTION at the moment.
NOTE NOTE NOTE
All u nderlined parameters ar e ac companied b y a T ool T ip, R ight-click o n t he
command to open the Tool Tip & x to close the Pop-up:
SEE ALSO:
About Power Quality Monitoring
Compliance Information
Compliance Chart
Events
PQ Compliance Configuration
