Elster 6 Series Wiring Instructions

Communication Connections
5
Page 18 of 31
Wiring Instructions
UFM Series 6
Pin Number
Signal Name
Description
14
D/I_RET2
Digital output 2 / current output 2 return
13
D/I_OUT2
Digital output 2 (open collector) / current
output 2
12
D/I_RET1
Digital output 1 / current output 1 return
11
D/I_OUT1
Digital output 1 (open collector) / current
output 1
10
FRET2
Frequency output 2 (return)
9
FOUT2
Frequency output 2 (open collector)
8
FRET1
Frequency output 1 (return)
7
FOUT1
Frequency output 1 (open collector)
6
RXD COM2
Serial port 2 RS232 receive / RS485 B
5
GND COM2
Serial port 2 RS232 ground
4
TXD COM2
Serial port 2 RS232 transmit / RS485 A
3
RXD COM1
Serial port 1 RS232 receive / RS485 B
2
GND COM1
Serial port 1 RS232 ground
1
TXD COM1
Serial port 1 RS232 transmit / RS485 A
Table 6: Field Terminal Board, TB3
TB3 is factory set according to Elster’s standard settings (see Table 7
below), unless for a specific order other settings have been agreed upon.
The user can change the settings using the SonicExplorer software through
a network connection.  See Chapter 5.1 Network (TB2 and J4) (p.14) for
more information.
