Elster A100C User Manual

32 A100C - BS Single Phase Electronic Meter
_____________________________________________________________________________
Display 1 Display 2 Display 3
Active
kWh
kWh
kWh Count Active
Export Hours
Segment Test kWh Import Cumulative kWh Import Rate 1 - Active
One dwell period on power up ptional in display sequence O
Optional in display sequence
Display 4 Display 5 Display 6
kWh
Active
Export
kWh Import Rate 2 - Inactive kWh Export Cumulative kWh Export Rate 1 - Active
Export
Optional in display sequence
Display 7 Display 8
Count
kWh Export Rate 2 - Inactive
Export
Reverse Run Count
Optional in display sequence
Display Nameplate
A100C
EN 62053-21 : 2003
kWh Cl. 1
1000 imp / kWh
220V 50Hz
=5 W h / P U L S E
20 - 100A
SJ1LABE-A
kWh
2004
Active
IrDA Tx
Count
Export
1 Reverse R un
kWh
Figure 7A - Typical 2 Rate Import/Export Meter Display
© Elster Metering Limited - M130 300 2C - 5.2007
