5 Technical Specifications
User’s Guide Flatpack2 Rectifier Modules, 350002.013, 7v0-2010-09 17
Applicable Standards
Electrical safety IEC 60950-1
UL 60950-1
CSA 22.2
EMC ETSI EN 300 386 V.1.3.2 (telecommunication network)
EN 61000-6-4 (emission, industry)
EN 61000-6-3 (emission, light industry)
EN 61000-6-2 (immunity, industry)
EN 61000-6-1 (immunity, light industry)
Telcordia NEBS GR1089 CORE
Mains Harmonics
EN 61000-3-2
Environment ETSI EN 300 019-2
ETSI EN 300 132-2
Telcordia NEBS GR63 CORE Zone 4
RoHS compliant
Specifications are subject to change without notice 241115.250.DS3 v3
Specifications Flatpack2 Rectifier 24V, 2000W WOR
AC Input
Voltage 85-300 VAC (Nominal 185 – 275 VAC)
Frequency
44 to 66Hz
Maximum
Current
12.5 A
rms
maximum at nominal input and
full load
Power Factor > 0.99 at 50% load or more
Input Protection
Varistors for transient protection
Mains fuse in both lines
Disconnect above 300 VAC
DC Output
Voltage
Adjustable range: 21.5-36.0VDC
Default voltage: 26.7 VDC
Output Power 2000 W at nominal input
Maximum Current
70.0 Amps at 29 VDC and nominal
input
Current Sharing ±5% of maximum current from 10% to
100% load
Static voltage
regulation
±0.5% from 10% to 100% load
Dynamic voltage
regulation
±5.0% for 10-90% or 90-10% load
variation, regulation time < 50ms
Hold up time > 20ms; output voltage > 21.5 VDC at
1500W load
Ripple and Noise < 100 mV peak to peak, 30 MHz
bandwidth
< 0.96 mV rms psophometric
Output
Protection
Overvoltage shutdown
Fuse on output
Short circuit proof
High temperature protection
Other Specifications
Efficiency Typical 91%
Isolation 3.0 KVAC – input and output
1.5 KVAC input earth
0.5 KVDC output earth
Alarms:
Low mains shutdown
High temperature shutdown
Rectifier Failure
Overvoltage shutdown on output
Fan failure, one or two fans.
Low voltage alarm at 21.0V
CAN bus failure
Warnings:
Low temperature shutdown
Rectifier in power derate mode
Remote battery current limit activated
Input voltage out of range, flashing at
overvoltage
Loss of CAN communication with
control unit, stand alone mode
Visual
indications
Green LED: ON, no faults
Red LED: rectifier failure
Yellow LED : rectifier warning
Operating
temp
-40 to +75°C (-40 to +167°F)
Storage temp -40 to +85°C (-40 to +185°F)
Cooling 2 fans (front to back airflow)
Fan Speed
Temperature and load regulated
MTBF > 200, 000 hours Telcordia SR-332 Issue I,
method III (a
) (T
ambient
: 25°C)
Acoustic
Noise
< 65dBA at nominal input and 70% load
(T
ambient
< 30°C)
Humidity
Operating: 5% to 95% RH non-
condensing
Storage: 0% to 99% RH non-condensing
Dimensions
109 x 41.5 x 327mm (wxhxd)
(4.25 x 1.69 x 13”)
Weight
1.9 kg (3.97 lbs)
