9. Annex 3: Connexion example – Helicopter
Battery
Plate S
ESC Motor
DC/DC
Pin 14 – V+
Pin 3 – CH3
Pin 5 – CH5
Pin1 – CH1
Pin 15 – V-
Plate NW
Pin 9 – GND
Plate NE
Tail
Pin 2 – CH2
Pin 4 – CH4
RPM
Pin 12 – ECAP
GPS antenna RF antennaStatic pressure Dynamic pressure
