The DAEs shown in Figure 114 on page 136, Figure 115 on page 137, and Figure 116 on
page 138 are:
◆ DAE 1, orange, 6-Gb/s SAS I/O module port 0 (SP A) to 1
st
DAE (EA 0/Bus 0) in rack 1
(labels SP A SAS 5 Port 0 to LCC A)
◆ DAE 1, orange, 6-Gb/s SAS I/O module port 0 (SP B) to 1
st
DAE (EA 0/Bus 0) in rack 1
(labels SP B SAS 5 Port 0 to LCC B)
◆ DAE 2, blue, 6-Gb/s SAS I/O module port 1 (SP A) to 2
nd
DAE (EA 0/Bus 1) in rack 1
(labels SP A SAS 5 Port 1 to LCC A)
◆ DAE 2, blue, 6-Gb/s SAS I/O module port 1 (SP B) to 2
nd
DAE (EA 0/Bus 1) in rack 1
(labels SP B SAS 5 Port 1 to LCC B)
◆ DAEs 3 through 9 are interleaved and daisy-chained between bus 0 and bus 1 in
rack 1. Or, EA 1/Bus 0 through EA 5/Bus 0 and EA 1/ Bus 1 though EA 4/Bus 1.
◆ In rack 2, DAEs 1 through 7 continue to interleave and daisy-chain between bus 0 and
bus 1. Or, EA 7/Bus 0 through EA 9/Bus 0 and EA 5/Bus 1 through EA 8/Bus 1.
◆ Then, starting with DAE 8, black, 6-Gb/s SAS I/O module port 2 (SP A) to 8
th
DAE
(EA 0/Bus 2) in rack 2 (labels SP A SAS 5 Port 2 to LCC A).
◆ DAE 8, black, 6-Gb/s SAS I/O module port 2 (SP B) to 8
th
DAE (EA 0/Bus 2) in rack 2
(labels SP B SAS 5 Port 2 to LCC B)
◆ DAE 9, green, 6-Gb/s SAS I/O module port 3 (SP A) to 9
th
DAE (EA 0/Bus 3) in rack 2
(labels SP A SAS 5 Port 3 to LCC A)
◆ DAE9, green, 6-Gb/s SAS I/O module port 3 (SP B) to 9
th
DAE (EA 0/Bus 3) in rack 2
(labels SP B SAS 5 Port 3 to LCC B)
◆ DAEs 10 through 20 are interleaved and daisy-chained between bus 2 and bus 3 in
rack 2. Or, EA 1/Bus 2 through EA 6/Bus 2 and EA 1/Bus 3 through EA 5/Bus 3.
◆ In rack 3, DAEs 1 through 9 continue to interleave and daisy-chain between bus 2 and
bus 3. Or, EA 5/Bus 3 through EA 9/Bus 3 and EA 6/Bus 2 through EA 9/Bus 2.
Note: Figure 114 on page 136 shows 10U of reserved space to allow for upgrading your
VNX8000 Block to VNX8000 File/Unified platform. If you are planning to upgrade your
Block platform to a File/Unified platform, it is recommended that at least 10U of rack
space be reserved for adding one to two 1U Controls Stations and one to four 2U Data
Mover enclosures.
