EMC VNX Series

I/O modules
EMC VNX8000 Hardware Information Guide 65
Figure 51 Four-port 8-Gb/s FC I/O module
Note: The 8-Gb/s I/O module uses a specific type of SFP module, ensure you are using the
correct one. Refer to the Parts Location guide for more information.
1 Push button latch handle 3 SFP+ (optical) port (four)
2 Power/fault LED 4 SFP+ link/activity LED
1
2
3
4
CNS-001752
