EMC2 VNX Series Hardware Information Guide

12 EMC VNX5400 Hardware Information Guide
VNX5400 product description
b.) Three 10/100/1000 LAN network management (RJ-45) ports
Note: The management module is secured with a latch handle (labeled MGMT).
– One CPU module consisting of one Intel Xeon 4-core 2.13-GHz processor. The
CPU modules in the DME contain the power, fault, and unsafe-to-remove LEDs
(see “CPU” on page 22 for more information).
– Six DDR3 synchronous dynamic RAM (SDRAM) slots supporting up to 6 GB per
CPU module using 2 or 4 GB DIMMs
– Three PCI Gen 2, 8x lane I/O module slots (0 – 2) available for use, supporting:
Note: The maximum number of I/O modules for the VNX5400 is three per DM.
One FC I/O module and up to two other I/O modules. Any combination of these
I/O modules must be the same for both Data Movers.
a.) One Fibre Channel (FC) I/O module with a:
– Four-port 8-Gb/s optical (running at 2, 4, or 8 Gb/s); in slot 0 only;
labeled 8 GbE Fibre on the latch handle
b.) One or two of the following network I/O modules in any combination:
– Two-port 10-Gb/s optical or active Twinax; labeled 10 GbE v3 on the
latch handle
– Four-port 1-Gb/s copper; labeled 1 GbE on the latch handle
– Two-port 10-Gb/s RJ45 Base-T iSCSI/IP; labeled 10 GbE Base-T on the
latch handle
◆ One to two 1U Control Stations
◆ A fully configured VNX5400 platform with a 3U DPE of 25 (2.5-inch disk drives) can
include up to nine 2U, 25 DAEs (a maximum of 225, 2.5-inch disk drives), up to fifteen
3U, 15 DAEs (a maximum of 225, 2.5- or 3.5-inch disk drives), up to one 3U, 120
DAEs
3
(a maximum of 120 2.5-inch disk drives), or up to three 4U, 60 DAEs
3
(a
maximum of 180, 2.5- or 3.5-inch disk drives). As a result, by using the DAEs
described above in this paragraph, the maximum disk drive capacity would become
250, 250, 145, or 205, respectively.
IMPORTANT
When calculating the number of disk drives for your VNX5400 platform, the DPE is
included in the total drive slot quantity of 250 drives. If the total drive slot quantity
exceeds 250, you will not be able to add another DAE. Refer to the “Disk-array
enclosures” section on page 69 for more information about the available expansion
DAEs for the VNX5400 platform.
◆ Any required cables including LAN cables, modem cables, and serial DB-9 cable.
◆ Mounting rails with hardware
◆ Front bezel with VNX5400 badge
3. When using a 3U, 120 or 4U, 60 DAE, a 40U Dense rack is required.
