EMC2 VNX Series Hardware Information Guide

VNX5400 DAE cabling
EMC VNX5400 Hardware Information Guide 125
Cable label wraps
Each VNX series platform comes with a cable label wrap guide or set of cable label wraps
to affix to the cables on your VNX series platform. These labels should be affixed to the
appropriate cables as you connect the cables to your VNX series platform. Figure 105
shows an example of the cable wrap guide and how to affix the cable label wrap to a
cable.
Note: If your VNX series platform was assembled at the factory, all the cable labels have
been affixed to the cables except for any DAEs you have ordered. Additionally, if your VNX
series platform was not assembled at the factory, the cable kit supplied with your product
will have all the required cables already labeled except for the DAEs.
Figure 105 Example of a cable label wrap
VNX5400 DAE cabling
IMPORTANT
The DAE (s) that are to be directly connected to the DPE need to be located close enough
to the DPE so that the DPE-to-DAE interconnect cables (that are provided with every DAE)
can be routed and connected to the DPE easily.
SP A SAS 0
SP A SAS 0
SP A SAS 0
SP A SAS 0
SP A SAS 0
SPA SAS 0
SPA SAS 0
SPA SAS 0
SPA SAS 0
VNX-000529
