VNX5400 product description
EMC VNX5400 Hardware Information Guide 9
Hardware features
Contained in a 9U architecture, the File/Unified VNX5400 platform weighs approximately
182.82 lb (82.925 kg) fully loaded
2
without I/O modules and DAEs. With the 3U DPE
having the deepest dimension within the cabinet, the File/Unified VNX5400 without DAEs
measures (9U) 12.25 inches high x 17.62 inches wide x 24.77 inches deep (31.11 cm x
44.76 cm x 69.92 cm). Between the front and rear of the enclosure, a midplane distributes
power and signals to all the enclosure components. On the front of the VNX5400 DPE, the
CPU modules, cooling fan modules, and disk drives plug directly into the midplane
connections. On the rear of the VNX5400 DPE, the battery backup unit (BBU) modules, the
base modules, power supply modules, management modules, and I/O modules plug
directly into the midplane connections.
Note: The previously mentioned dimensions are approximate and do not include any I/O
modules, DAEs, or the cabinet enclosure.
For more information about the weight and dimensions of a VNX5400 platform, go to
https://mydocs.emc.com/VNX/ and go to the About VNX section, and then select View
technical specifications. Next, follow the steps in the wizard.
Configured for AC-input power, the VNX5400 platform includes the following hardware
features:
Note: A DC powered VNX5400 model is also available.
2. A fully loaded VNX5400 (without any DAEs) includes two 1U Control Stations, one 3U DPE (with
two SPs), and two 2U Data Mover enclosure with four Data Movers. In this fully loaded File/Unified
VNX5400 platform, the 3U DPE (with two SPs) can have 25 (2.5-inch) disk drives. Separately, the
25 (2.5-inch) drives weigh 13.5 lb (6.13 kg).
Table 2 Block and File VNX5400 platform hardware feature quick reference
Minimum
form
factor
Maximum
# of
drives
Drive
types
Block File
Config.
I/O
slots
per SP
Built-in
I/O ports
per SP SPs
System
memory
per SP Protocols
Config.
I/O slots
per DM DMs
System
memory
per DM Protocols
3U w/out
optional
CS,
DMEs,
and DAEs
250 6-Gb/s
2.5 or
3.5 in.
SAS
and
2.5 or
3.5 in.
Flash
4
1
Two 4x
lane BE
2
6-Gb/s
mini-SAS
ports
2 16 GB FC, iSCSI,
and FCoE
3 1 to 4
3
6 GB NFS,
CIFS,
and
pNFS
4
1. For the type and number of Ultraflex I/O modules supported in the SP, refer to the I/O module section on page “Storage processor I/O module
types” on page 46.
2. BE = back end
3. For the type and number of Ultraflex I/O modules supported in the DM, refer to the I/O module section on page “Data Mover I/O module types” on
page 60.
4. pNFS = parallel-NFS
