Emec F Series - B Appendix. Construction Materials and Technical Info

32
B Appendix. Construction Materials and Technical info
Flow
Max
Capacity
l/h
Ma
x
Pressure
bar
Capacity
l/h
Pressure
bar
ml stroke
Strokes/
min
H oses
mm
Watt
W
Shipping
weight
Kg
12 1,5
1,5 12 2,5 6 0,17
150 4x6 16W 2,2
10 2,2
2,2
10
3 5 0,25 150 4x6
16W 2,2
07 03
3 7 4 3,5 0,34 150 4x6
16W 2,2
07 05
5 7 7 3,5 0,56 150 4x6 16W 2,2
06 06
6 6 8
3 0,67 150 4x6 16W 2,2
05 07
7 5 8 2,5 0,78 150 4x6 16W 2,2
05 05
5 5 7 2,5 0,56 150 4x6 16W 2,2
03 6,5
6,5 3 7,5 1,5 0,72 150 4x6 16W 2,2
03 8,5
8,5 3 10,4 1,5 0,94 150 4x6 19W 2,2
10 05
5 10 6,5 5 0,56 150 4x6 19W 2,2
05 10
10 5 12 2,5 1,00 166 4x6 19W 2,2
03 11
11 3 13,1 1,5 1,10 166 4x6 19W 2,2
05 0,2
0,2 5 0,9 2,5 0,25 15 4x6 16W 2,2
TECHNICALFEATURES
Power supply: 230VAC(180-270VAC)
Power supply: 115VAC(90-135VAC)
Power supply: 24VAC(20-32VAC)
Power supply: 12VDC(10-16VDC)
Pump strokes: 0÷150
Suction Height: 1,5metres
Environment Temperature: 0÷45°C(32÷113°F)
Chemical Temperature: 0÷50°C(32÷122°F)
Installation Class: II
Pollution Level: 2
Audible Noise: 74dbA
Packaging and Transporting Temperature: -10÷+50°C
Protection degree IP65
MANUFACTURINGMATERIALS
Case:   PP
Pump head: PP,PVDF,PMMA,SS*
Diaphragm:   PTFE
Balls:   CERAMIC,GLASS,PTFE,SS*
Suction Pipe  PVC/PE**
Delivery Pipe:  PE
Valve Body:  PP,PVDF,SS*
O-ring:   FP,EP,WAX,SI,PTFE*
Injection connector  PP,PVDF(ceramic,HASTELLOYC276spring)
Level Probe:  PP,PVDF*
Level probe cable:  PE
Foot Filter: PP,PVDF*
*asordered.
**accordingwithpump’smodel.
