F Appendix. “F” and “FA” series pump installation drawings
1)Injectionvalve 2)Injectionhose 3)Safetybreaker 4)Controlpanel 5)Pumphead 6)Powercable 7)Outgassinghose 8)Suctionhose 9)Levelprobe 10)Footfilter
1)Injectionvalve 2)Injectionhose 3)Safetybreaker 4)Controlpanel 5)Pumphead 6)Powercable 7)Outgassinghose 8)Suctionhose 10)Footfilter
FCO/FCE
FCL
