Emec F Series - General Description

7
3. General description
On/Offbutton
Deliveryvalve
Dischargehose
Powersupply
Suctionvalve
Strokespeedknob
Dischargeknob
On/OffLed-Pump’spulses
Note:
Shownimagedoesnotrepresentaspecificpump’smodel.Itisonlyforgeneralpurpose.
LevelProbeInput
ExternalSignalInput
WARNING
IF EQUIPMENT IS NOT SUPPLIED WITH A PLUG:
a) a switch or circuit-breaker shall be included in the building installation
b) it shall be in close proximity to the equipment and within easy reach of the operator
c) it shall be marked as the disconnetting device for the equipment
WARNING
IF EQUIPMENT IS SUPPLIED WITH A PLUG:
If an appliance coupler or separable plug is used as the disconnecting device, it shall be readily
identifiable and easily reached by the operator. For single-phase portable equipment, a plug on
a cord of length not greater than 3m is considered to be easily reached.
