5. Installation draw
Pumpmustbeinstalledinastablesupportatamaximumheight(fromtank’sbottom)of1,5meters.
1.Injectionvalve
2.Deliveryhose
3.Safetybreaker
4.Controlpanel
5.Pumphead
6.Powercable
7.Outgassinghose
8.Suctionhose
9.Footfilter
1
2
3
4
5
6
7
8
9
