FDR
1)Injectionvalve 2)Injectionhose 3)ControlPanel 4)PulseSenderWaterMeter 5)Safetybreaker 6)Powercable 7)PumpHead 8)Levelprobe 9)Outgassinghose 10)Suctionhose 11)Footfilter
1)Injectionvalve 2)Electrovalve 3)Safetybreaker 4)Controlpanel 5)Pumphead 6)Powercable 7)Outgassinghose 8)Suctionhose 9)Footfilter+levelprobe
F Appendix. “F” and “FA” series pump installation drawings
