If parameter copying is enabled when no SmartStick is installed into the drive, the drive’s display will show a C.Acc trip.
The SmartStick should be fully inserted or removed from the drive before a drive reset is performed.
If this parameter is set to a non-zero value and edit mode is exited or the drive is reset when the drive is inactive, the selected default parameters will
automatically be loaded. After the parameters have been set to default values they are automatically saved to the drive’s internal EEPROM. If the
drive is active the display will flash FAIL once and then Pr 11.43 will be set back to no.
This read write parameter defines the level of security for menu 0.
The LED keypad can adjust this parameter even when user security is set.
Parameter number Function
2.08 Standard ramp voltage
4.07, 21.29 Current limits
5.07, 21.07 Motor rated currents
5.09, 21.09 Motor rated voltages
5.10, 21.10 Motor rated power factor
5.17, 21.12 Stator resistances
5.18 Switching frequency
5.23, 21.13 Voltage offsets
5.24, 21.14 Transient inductances
6.06 DC injection braking current
11.43 Load defaults {29}
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range no(0), Eur(1), USA(2)
Default no(0)
Update rate Actioned on exit of edit mode or drive reset
Value Display Function
0 no No action
1 Eur Load European defaults
2 USA Load USA defaults
Disconnect the electro-mechanical brake circuit before performing a default.
11.44 Security status {10}
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 1 111
Range L1(0), L2(1), L3(2), LoC(3)
Default L1(0)
Update rate Actioned on exit of edit mode
Value Level Access permitted
0 L1 Only the first ten parameters can be accessed.
1 L2 Parameters up to 60 can be accessed.
2 L3 Parameters up to 95 can be accessed.
3 LoC
Lock security, so that the security code must be entered before a parameter can
be edited and set security status to L1.
