Emerson 2403 - Real Time Clock Update Mode; Minutes;Seconds; Days;Hours; Real Time Clock Month;Date; Real Time Clock Years; Analog Input 1 Mode (Terminal T2)

Menu 15
I/O options
Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
180 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 9
0: Real time clock parameters controlled by real time clock
1: Real time clock parameters controlled by user
2: Real time clock reads real time clock parameters and sets Pr 15.30 to 0
The real time clock is not available on SM-I/O Lite.
When an option with a real time clock is installed, Pr 15.34 to Pr 15.37 will be controlled by the option.
Pr 15.34 to Pr 15.37 are not available on SM-I/O Lite
Terminal T2 is a voltage/current reference input. The setting of this parameter configures the terminal to the required mode
15.30 Real time clock update mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
Range 0 to 2
Default 0
Update rate Background read/write
15.31 to 15.33 Unused parameters
15.34 Real time clock minutes/seconds
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range 00.00 to 59.59
Default 00.00
Update rate Background read/write
15.35 Real time clock days/hours
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range 1.00 to 7.23
Default 00.0
Update rate Background read/write
15.36 Real time clock month/date
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range 00.00 to 12.31
Default 00.00
Update rate Background read/write
15.37 Real time clock years
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 2000 to 2099
Default 2000
Update rate Background read/write
15.38 Analog input 1 mode (Terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0-20(0), 20-0(1), 4-20(2), 20-4(3), 4-.20(4), 20-.4(5), VoLt(6)
Default 0-20(0)
Update rate On drive reset
NOTE
NOTE
