USER’S MANUAL
February 2009
375 FIELD COMMUNICATOR
APPENDIX CGRAPHICS INFORMATION
OVERVIEW The Graphics functionality enables a new, sleek user
interface design by using enhanced Electronic Device
Description Language (EDDL) capabilities. You can now
view HART or fieldbus device information as images,
charts, and graphs.
To view the graphical representations, you need a device
with enhanced EDDL, 375 system software version 2.0
or higher, and a 375 Field Communicator with a
Graphics license, which can be enabled in your 375
Field Communicator from the Easy Upgrade
Programming Utility. See the Easy Upgrade
Programming Utility online Help for more information.
The following sections provide details on the screen
layout, the buttons used to modify the graphics, and the
graphics options.
