Hoist Ring lookup table for Daniel 3415, 3416 and 3417 gas meters
(continued)
Table 2-2:
ANSI 300 ANSI 600 Daniel Part Number Thread
- - 1-504-90-093 3/4"
- - 1-504-90-094 1"
- - 1-504-90-095 1 1/2"
Appropriately rated lifting slings
The following instructions are intended to provide general guidelines for using proper
lifting slings when lifting a Daniel 3410 Series Gas Ultrasonic Flow Meter by itself. These
instructions are intended to be followed in addition to your company's standards or the
DOE-STD-1090-2004 Hoisting and Rigging standard if such company standards do not
exist.
Safety precautions using appropriate rated lifting slings
1. Meters must only be lifted by personnel properly trained in the safe practices of
rigging and lifting.
2. NEVER attempt to lift the meter by wrapping slings around the electronics
enclosure.
3. NEVER attempt to lift the meter using only one sling around the meter. Always use
two slings wrapped around each end of the body as shown below. A choker style
sling is recommended.
Mechanical installation
Installation manual 41
