Table 1-17: Part description for an NPS 3 bidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-114 1-504-05-114 2
54 Shaft 1-504-05-622 1-504-05-622 1
55 Bladed rotor 1-307-11-235 1-307-11-236 1
60 Nut 1-561-76-192 1-561-76-192 2
62 Upstream cone-rimmed 1-307-10-435 1-307-10-439 2
Upstream cone-bladed 1-307-10-437 1-307-10-438 2
68 Housing insert 1-307-03-000 1-307-03-020 2
69 Hanger blades 1-307-10-735 1-307-10-736 6
71 Hanger hub 1-307-10-635 1-307-10-636 2
72 Rimmed rotor 1-307-11-237 1-307-11-238 1
Table 1-18: Part description for an NPS 4 bidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-115 1-504-05-115 2
54 Shaft 1-504-05-627 1-504-05-627 1
55 Bladed rotor 1-307-11-300 1-307-11-301 1
60 Nut 1-561-76-155 1-561-76-155 2
62 Upstream cone-rimmed 1-307-10-440 1-307-10-444 2
Upstream cone-bladed 1-307-10-442 1-307-10-443 2
68 Housing insert 1-307-03-001 1-307-03-021 2
69 Hanger blades 1-307-10-740 1-307-10-741 6
71 Hanger hub 1-307-10-640 1-307-10-641 2
72 Rimmed rotor 1-307-11-302 1-307-11-303 1
Introduction User manual
March 2019 P/N 3-9008-515
38 Daniel Series 1500 Liquid Turbine Meter, NPS 3-24
