Digitax ST Installation Guide 11
Issue: 2 www.controltechniques.com
Safety Information Introduction
Mechanical Installation
Electrical Installation
3 Mechanical Installation
3.1 Drive
The drive complies with the requirements of IP20 as standard.
Figure 3-1 Dimensions
Enclosure
The drive is intended to be mounted in an enclosure which prevents access except by
trained and authorized personnel, and which prevents the ingress of contamination. It is
designed for use in an environment classified as pollution degree 2 in accordance with
IEC 60664-1. This means that only dry, non-conducting contamination is acceptable.
WARNING
62mm
(2.44in)
249.7mm
(9.83in)
220mm (8.66in)
47mm
(1.85in)
7.5mm
(0.3in)
304mm
(11.96in
To Next Page
