Page #111 background imageLoading...
Page #111 background image
Safety
Information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
EtherCAT
interface
SMARTCARD
Operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL listing
information
Digitax ST User Guide 111
Issue Number: 5
Table 12-3 Feature look-up table
Feature Parameter number (Pr)
Acceleration rates 2.10 2.11 to 2.19 2.32 2.33 2.34 2.02
Analog speed reference 1 1.36 7.10 7.01 7.07 7.08 7.09 7.25 7.26 7.30
Analog speed reference 2 1.37 7.14 1.41 7.02 7.11 7.12 7.13 7.28 7.31
Analog I/O Menu 7
Analog input 1 7.01 7.07 7.08 7.09 7.10 7.25 7.26 7.30
Analog input 2 7.02 7.11 7.12 7.13 7.14 7.28 7.31
Analog input 3 7.03 7.15 7.16 7.17 7.18 7.29 7.32
Analog output 1 7.19 7.20 7.21 7.33
Analog output 2 7.22 7.23 7.24
Application menu Menu 18 Menu 19 Menu 20
At speed indicator bit 3.06 3.07 3.09 10.06 10.05 10.07
Auto reset 10.34 10.35 10.36 10.01
Autotune 5.12 5.17 5.24
Binary sum 9.29 9.30 9.31 9.32 9.33 9.34
Bipolar speed 1.10
Brake control 12.40 to 12.49
Braking 10.11 10.10 10.30 10.31 6.01 2.04 2.02 10.12 10.39 10.40
Copying 11.42 11.36 to 11.40
Stop mode 6.01
Comms 11.23 to 11.26
Cost - per kWh electricity 6.16 6.17 6.24 6.25 6.26 6.40
Current controller 4.13 4.14
Current feedback 4.01 4.02 4.17 4.04 4.12 4.20 4.23 4.24 10.08 10.09 10.17
Current limits 4.05 4.06 4.07 4.18 4.15 4.19 4.16 5.07 10.08 10.09 10.17
DC bus voltage 5.05 2.08
Deceleration rates 2.20 2.21 to 2.29 2.04 2.35 to 2.37 2.02 2.04 2.08 6.01 10.30 10.31 10.39
Defaults 11.43 11.46
Digital I/O Menu 8
Digital I/O read word 8.20
Digital I/O T24 8.01 8.11 8.21 8.31
Digital I/O T25 8.02 8.12 8.22 8.32
Digital I/O T26 8.03 8.13 8.23 8.33
Digital input T27 8.04 8.14 8.24
Digital input T28 8.05 8.15 8.25 8.39
Digital input T29 8.06 8.16 8.26 8.39
Digital lock 13.10 13.01 to 13.09 13.11 13.12 13.16 3.22 3.23 13.19 to 13.23
Digital output T22 8.08 8.18 8.28
Direction 10.13 6.30 6.31 1.03 10.14 2.01 3.02 8.03 8.04 10.40
Display timeout 11.41
Drive active 10.02 10.40
Drive derivative 11.28
Drive ok 10.01 8.27 8.07 8.17 10.36 10.40
Dynamic performance 5.26
Electronic nameplate 3.49
Enable 6.15 8.09 8.10
Encoder reference 3.43 3.44 3.45 3.46
Encoder set up 3.33 3.34 to 3.42 3.47 3.48
External trip 10.32 8.10 8.07
Fan speed 6.45
Fast disable 6.29
Field weakening 5.22 1.06
Filter change 6.19 6.18
Speed reference selection 1.14 1.15
Speed slaving 3.01 3.13 3.14 3.15 3.16 3.17 3.18
Hard speed reference 3.22 3.23
Current rating 5.07 11.32
I/O sequencer 6.04 6.30 6.31 6.32 6.33 6.34 6.42 6.43 6.41
Inertia compensation 2.38 5.12 4.22 3.18
Jog reference 1.05 2.19 2.29
Ke 5.33
Keypad reference 1.17 1.14 1.43 1.51 6.12 6.13
Kt 5.32
Limit switches 6.35 6.36
Line power supply loss 6.03 10.15 10.16 5.05
Local position reference 13.20 to 13.23
Logic function 1 9.01 9.04 9.05 9.06 9.07 9.08 9.09 9.10
Logic function 2 9.02 9.14 9.15 9.16 9.17 9.18 9.19 9.20
