Digitax ST User Guide 193
Issue: 5
SLX.Er Solutions Module slot X trip: Solutions Module in slot X or Digitax ST EZMotion has detected a fault
202,207,212
Automation (EZMotion) module category
Check value in Pr 17.50. The following table lists the possible error codes for the Digitax ST EZMotion. See the Advanced parameter
section in the Digitax ST Advanced User Guide for more information.
Trip Diagnosis
Error Code Trip Description
41 Digitax ST parameter access error - Parameter does not exist
42 Digitax ST parameter access error - Parameter is read-only
43 Digitax ST parameter access error - Parameter is write-only
44 Digitax ST parameter access error - Written value out of range
73 Digitax ST database set-up error
74 Module overheat error
101 Invalid configuration error
102 NVM invalid error
103 Power up test failure error
104 Following error
105 Travel limit plus
106 Travel limit minus
107 No program error
108 Motion trajectory error
109 Trajectory update overrun error
120
File corruption error - Consult factory121
122
123 Program error - Buffer overrun
124 Program error - Call stack overflow
125
File corruption error - Consult factory
126
127 Flash error
128 File corruption error - Consult factory
129 Program error - illegal command
130
File corruption error - Consult factory
131
132
133
134
135 Program error - Math addition overflow
136 Program error - Math divide by zero
137 Program error - Math divide operand too large
138 Program error - Math multiplication normalization failed
139 Program error - Math divide operand too large
140 Program error - Overflow
141 Program error - Math subtraction overflow
142 Program error - Math stack overflow
143
File corruption error - Consult factory
144
145
146
147 Program error - Flash memory size exceeded
148 Program error - RAM memory size exceeded
153
File corruption error - Consult factory154
155
156 Program error - Too many wait for instructions
157
File corruption error - Consult factory
158
159
160
161
162
163
164
165
166 Program error - EZMotion parameter write out of range
171 Invalid slot 1 selection
172 Invalid slot 2 selection
173 Invalid motion processor
174 File corruption error - Consult factory
175 Module output overload
