194 Digitax ST User Guide
Issue: 5
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202,207,212
Automation (I/O Expansion) module category
Check value in Pr 15/16.50. The following table lists the possible error codes for the SM-I/O Plus, SM-I/O Lite, SM-I/O Timer, SM-I/O
PELV, SM-I/O 120 V and SM-I/O 24 V Protected. See the Diagnostics section in the relevant Solutions Module User Guide for more
information.
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202,207,212
Fieldbus module category
Check value in Pr 15/16.50. The following table lists the possible error codes for the Fieldbus modules. See the Diagnostics section
in the relevant Solutions Module User Guide for more information.
Trip Diagnosis
Error code Module Reason for fault
0AllNo errors
1 All Digital output overload
2
SM-I/O Lite, SM-I/O Timer
Analog input 1 current input too high (>22 mA) or too low (<3 mA)
SM-I/O PELV, SM-I/O 24V Protected Digital input overload
3
SM-I/O PELV, SM-I/O 24V Protected Analog input 1 current input too low (<3 mA)
SM-I/O 24V Protected Communications error
4 SM-I/O PELV User power supply absent
5 SM-I/O Timer Real time clock communication error
74 All Module over temperature
Error code Module Trip Description
0 All No trip
52
SM-PROFIBUS-DP-V1, SM-Interbus,
SM-DeviceNet, SM-CANOpen
User control word trip
61
SM-PROFIBUS-DP-V1, SM-Interbus,
SM-DeviceNet, SM-CANOpen, SM-SERCOS
Configuration error
64 SM-DeviceNet Expected packet rate timeout
65
SM-PROFIBUS-DP-V1, SM-Interbus,
SM-DeviceNet, SM-CANOpen, SM-SERCOS
Network loss
66
SM-PROFIBUS-DP-V1 Critical link failure
SM-CAN, SM-DeviceNet, SM-CANOpen Bus off error
69 SM-CAN No acknowledgement
70
All (except SM-Ethernet) Flash transfer error
SM-Ethernet No valid menu data available for the module from the drive
74 All Solutions module over temperature
75 SM-Ethernet The drive is not responding
76 SM-Ethernet The Modbus connection has timed out
80 All (except SM-SERCOS) Inter-option communications error
81 All (except SM-SERCOS) Communications error to slot 1
82 All (except SM-SERCOS) Communications error to slot 2
83 All (except SM-SERCOS) Communications error to slot 3
84
SM-Ethernet Memory allocation error
85
SM-Ethernet File system error
86
SM-Ethernet Configuration file error
87
SM-Ethernet Language file error
98 All
Internal watchdog error
99 All
Internal software error
