Safety
Information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running
the motor
Optimization
EtherCAT
interface
SMARTCARD
Operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL listing
information
Digitax ST User Guide 61
Issue: 5
Figure 7-1 Minimum connections to get the motor running via Serial Communications (e.g. CTSoft)
U
VW
30
31
28
29
26
27
24
25
23
21
22
SAFE TORQUE
OFF(drive
enable - T31)
24V
UVW
A A
B B
U U
V V
W W
Z Z
Encoder connector
15 way D-type
5
10
15
1
6
11
Serial
communications
port
External
braking
resistor
(optional)
L3/NL2
L1
L2
L1
Fuses
Serial Comms
User Interface
Isolated serial
comms lead
DST12XX = 200 to 240V 10%
DST14XX = 380 to 480V 10%
±
±
Part number Description
CT EIA232
Comms cable
CT USB
Comms cable
4500-0087
4500-0096
Internal
braking
resistor
(optional)
Thermal
overload
protection
device
Polarized signal
connections
Terminals Torque setting*
Power terminals
1.0 N m
(12.1 lb in)
Control terminals
0.2 N m
(1.7 lb in)
Status relay
terminals
0.5 N m
(4.5 lb in)
Ground terminal
screws
4 N m
(35 lb in)
Small ground
terminal screws
2 Nm
(17.7 Ib in)
* Torque tolerance = 10%
