Emerson Digitax ST User Manual

Safety
Information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running
the motor
Optimization
EtherCAT
interface
SMARTCARD
Operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL listing
information
62 Digitax ST User Guide
Issue: 5
Figure 7-2 Minimum connections to get the motor running via keypad
U
VW
30
31
28
29
26
27
24
25
23
21
22
24V
UVW
A A
B B
U U
V V
W W
Z Z
Encoder connector
15 way D-type
5
10
15
1
6
11
L3/NL2L1
L2
L1
Fuses
DST12XX = 200 to 240V 10%
DST14XX = 380 to 480V 10%
±
±
Internal
braking
resistor
(optional)
External
braking
resistor
(optional)
Thermal
overload
protection
device
Polarized signal
connections
SAFE TORQUE
OFF(drive
enable - T31)
Terminals Torque setting*
Power terminals
1.0 N m
(12.1 lb in)
Control terminals
0.2 N m
(1.7 lb in)
Status relay
terminals
0.5 N m
(4.5 lb in)
Ground terminal
screws
4 N m
(35 lb in)
Small ground
terminal screws
2 Nm
(17.7 Ib in)
* Torque tolerance = 10%
