Data of pre-configured valves
Parameter
Ec9/Ec18
Model
Ec14 /
Ec23
(steps
*10)
Ec13 /
Ec22
(steps*10
)
Ec15 /
Ec24
(mA*10)
Ec16 /
Ec25
(mA*10)
Ec50
/Ec52
Ec51/
Ec53
0
Manual
setting
Config
.
Config.
Config.
Config.
Config.
Config.
1
Danfoss
ETS-25/50
0
2625
10
10
1
1
2
Danfoss
ETS-100
0
3530
10
10
1
1
3
Danfoss
ETS-250/400
0
3810
10
10
1
1
4
Alco
EX4-EX5-EX6
0
750
50
10
1
1
5
Alco EX7
0
1600
75
25
1
1
6
Alco EX8 500
0
2600
80
50
1
1
7
Configuration
1
50
480
45
10
0
0
8
Configuration
2
50
380
45
10
0
0
7.3.2 Parameters to set in the event of manual configuration of the valve
Ec13/Ec22 maximum number of steps of valve
Refer to the technical documentation of the valve to set this parameter correctly.
(this value is set automatically by the controller if EC9> 0 and / or EC18> 0)
Ec14/Ec23 Minimum number of valve steps
Refer to the technical documentation of the valve to set this parameter correctly.
(this value is set automatically by the controller if EC9> 0 and / or EC18> 0)
Ec15/Ec24 maximum movement current
Refer to the technical documentation of the valve to set this parameter correctly.
(this value is set automatically by the controller if EC9> 0 and / or EC18> 0)
Ec16/Ec25 Holding current value
Refer to the technical documentation of the valve to set this parameter correctly.
(this value is set automatically by the controller if EC9> 0 and / or EC18> 0)
Ec50/Ec52 Setting of the kind of movement current
Valve manufacturers use different ways of controlling them; parameters Ec50/Ec52 are used to
establish whether the movement current value is a peak value or an RMS value in MICROSTEPPING
ADJUSTMENT mode.
