1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 25/56
17.2.2 Condenser probe configuration
P2c: Condenser probe setting (probe 2):
nP = not used:
Cur = 4 ÷ 20 mA pressure transducer; use term. 6(+), 7 (in); 10 (gnd) if present
tEn = 0.5÷4.5V ratiometric pressure transducer; use term. . 4(+), 7 (in); 10 (gnd
ntc = NTC 10K probe; use term. 4-7
FA04: Adjustment of read out for the Probe 2 (used only if P2c=Cur or tEn). corresponding
to 4mA or 0.5V input signal, given by the delivery probe
(-1.0 ÷ FA20bar; -15÷FA20PSI; -100 ÷ FA20KPA)
FA20: Adjustment of read out for the Probe 2 corresponding to 20mA or 4.5V input signal,
given by the condensing probe (FA04 ÷ 61.0BAR; FA04 ÷ 885PSI; FA04 ÷ 6100KPA)
FCAL: Probe 2 calibration the range depends on the dEU parameter:
dEU=bar or °C: -12.0÷12.0;
dEU=PSI or °F: -200÷200;
dEU=kPA: -999÷999;
17.2.3 Probe 3 configuration
P3c: Probe 3 setting:
nP = not used:
Cur = 4 ÷ 20 mA pressure transducer; use term. 6(+), 3 (in); 10 (gnd) if present
tEn = 0.5÷4.5V ratiometric pressure transducer; use term. . 4(+), 3 (in); 10 (gnd
nt10 = NTC 10K probe; use term. 3-4
nt86 = NTC 86K use term. 3-4
3P04: Adjustment of read out for the Probe 3 (used only if P3c=Cur or tEn). corresponding
to 4mA or 0.5V input signal, given by the delivery probe
(-1.0 ÷ 3P20bar; -15÷3P20 PSI; -100 ÷ 3P20 KPA)
3P20: Adjustment of read out for the Probe 3 corresponding to 20mA or 4.5V input signal,
given by the condensing probe (3P04 ÷ 61.0BAR; 3P04 ÷ 885PSI; 3P04 ÷ 6100KPA)
O3: Probe 3 calibration the range depends on the dEU parameter:
dEU=bar or °C: -12.0÷12.0;
dEU=PSI or °F: -200÷200;
dEU=kPA: -999÷999;
17.2.4 Probe 4 configuration
P4c: Probe 4 setting (33-34):
nP = not used:
nt10 = NTC 10K
nt86 = NTC 86K
ntcH = NTC 10K extended range (150°C)
O4: Probe 4 calibration the range depends on the dEU parameter:
dEU= °C: -12.0÷12.0;
dEU= °F: -200÷200;
17.2.5 Probe selection second suction circuit
2CPb: Probe selection for second suction circuit
nP = not used:
P1 = Probe 1 – NOT SET IT: already used for first suction circuit
P2 = Probe 2 – NOT SET IT : already used for fan
P3 = Probe 3 – SET this probe!
17.2.6 Probe selection for fan
FPb: Probe selection for condenser fan
nP = not used:
P1 = Probe 1
P2 = Probe 2 – Factory setting
