P3 = Probe 3
17.3 Configurable digital inputs configuration
iF01 Digital input 1 configuration (10-13)
nu = Not used: the digital input is disabled.
oA1= Safety digital input for load 1, term. 15-17/19; (Factory setting);
oA2 = Safety digital input for load 2, term. 16-17/19
oA3 = Safety digital input for load 3, term. 18-21/22
oA4 = Safety digital input for load 4, term. 20-21/22
oA5 = Safety digital input for load 5, term. 25/26
oA6 = Safety digital input for load 6, term. 27-28
inF = Safety digital input of inverter for fan, used when none relay is configured as inverter
for fans
LP1 = low pressure switch, circuit1
LP2 = low pressure switch, circuit2
HP = High pressure switch
ES = Energy saving;
oFF = instrument shut down;
LL = liquid level alarm
SIL = to enable the silence function
EAL = generic external alarm, it doesn’t affect the regulation
Co1 = running proof function for load 1, term. 15-17/19
Co2 = running proof function for load 2, term. 16-17/19
Co3 = running proof function for load 3, term. 18-21/22
Co4 = running proof function for load 4, term. 20-21/22
Co5 = running proof function for load 5, term. 25/26
Co6 = running proof function for load 6, term. 27-28
iF02 Digital input 2 configuration (10-14) – For the values see iF01; Factory setting oA2.
iF03 Digital input 3 configuration (10-11) – For the value see iF01; Factory setting oA3
iF04 Digital input 4 configuration (10-12) – For the value see iF01; Factory setting oA4
iF05 Digital input 5 configuration (9-10) – For the value see iF01; Factory setting LP1
iF06 Digital input 6 configuration (31-32) – For the value see iF01; Factory setting HP
iF07 Digital input 7 configuration (33-34) ) – For the value see iF01; Factory setting oA5
NB: Digital input 7 is enabled only when P4C=NP, otherwise it operates as
temperature probe
iP01 Digital input 1 polarity (10-13):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP02 Digital input 2 polarity (10-14):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP03 Digital input 3 polarity (10-11):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP04 Digital input 4 polarity (10-12):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP05 Digital input 5 polarity (9-10):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP06 Digital input 6 polarity (31-32):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
iP07 Digital input 7 polarity (33-34):
oP: the digital input is activated by opening the contact;
CL: the digital input is activated by closing the contact.
