4. TECHNICAL DATA
Indoor use, Open Type (NEMA - UL 50e)
IP20 (EN60529)
Ambient Operating
Temperature
Shipping and storage
temperature
Field wiring terminal
identification, wire size and
torque value
The serial line cable can be of the two-wire type plus the shield, with a
minimum section of 0.5mm2 (eg BELDEN 8772).
Internal battery and RTC
accuracy
Rechargeable and non-removable lithium battery. 50ppm for temperature
variation up to 60 ° C, 5ppm for aging. The maximum drift of the clock in a
year is therefore 33 min per year
Optoisolated with common at + 12Vdc (isolated), connectable via 2-way
terminal block. Present only for XWEB500D
AUX1-2-3 clean contacts for 24/120 / 240Vac max 5A resistive loads.
AUX1 port ("Systema Alarm") in exchange; connectable via 3-way
terminal block; always present. AUX2 ('Alarm 1') and AUX3 ('Alarm 2')
ports that can be connected via a 2-way terminal block; present only for
XWEB500D.
"Pwr Ext Modem" clean contacts 12Vdc max 250mA connectable via 2-
way terminal block; always present
RS485 port 1: optically isolated (always present)
RS485 port 2: optically isolated (only for XWEB500D)
1 standard HOST connector type A port
Maximum deliverable current 500 mA
Incorporated control, intended to be used in Class I or Class II equipment
CE, UL. The system consisting of this control and monitoring unit and
Dixell temperature meters compliant with the EN13485 standard complies
with the EC regulation no. 37/2005 and in particular with the EN12830
standard. Temperature recorders for the transport and storage and
distribution of chilled, frozen, deep-frozen and ice-cream products (UNI
EN 12830, S, A, 1, measurement range corresponding to the class of
connected devices)
The terminal board for connecting the relays can be used to directly
drive high voltage loads (higher than 24V) but the voltages between
the different terminals cannot be mixed.
