Section 9: Electrical Connection
• Move valve to mid-position by handwheel. This will allow sufcient time to stop
actuator in case of improper hook-up or reversed power phases.
• Identify means of removing power during hookup.
• Be sure no erroneous remote control signals can be received causing actuator
to energize.
• Electrically operate the valve in the open direction. If the valve closes, actuator
must be stopped and the power leads reversed to correct voltage phasing or
improper eld wiring.
• Set all eld conduit entries in accordance with National Electric Code Requirements.
!
WARNING
Improper power voltage phasing eliminates protection of both the position limit switch and
torque switches, risking valve damage.
