DVC6000f Digital Valve Controllers
December 2009
1-6
Table 1-1. Specifications (continued)
Independent Linearity
(6)
±0.5% of output span
Electromagnetic Compatibility
Meets EN 61326-1 (First Edition)
Immunity—Industrial locations per Table 2 of the
EN 61326-1 standard. Performance is shown
in table 1-2 below
Emissions—Class A
ISM equipment rating: Group 1, Class A
Lightning and Surge Protection—The degree of
immunity to lightning is specified as Surge immunity
in table 1-2. For additional surge protection
commercially available transient protection devices
can be used.
Vibration Testing Method
Tested per ANSI/ISA-75.13.01 Section 5.3.5. A
resonant frequency search is performed on all three
axes. The instrument is subjected to the ISA
specified 1/2 hour endurance test at each major
resonance, plus an additional two million cycles.
Operating Ambient Temperature Limits
(2)
−40 to 80C (−40 to 176F) for most approved
valve-mounted instruments.
−60 to 125C (−76 to 257F) for remote-mounted
feedback unit.
−52 to 80C (−62 to 176F) for valve-mounted
instruments utilizing the Extreme Temperature
option (fluorosilicone elastomers)
Electrical Classification
CSA— Intrinsically Safe, and FISCO, Explosion
proof, Division 2, Dust-Ignition proof
FM— Intrinsically Safe and FISCO, Explosion
proof, Non-incendive, Dust-Ignition proof
ATEX—Intrinsically Safe and FISCO, Flameproof,
Type n
IECEx— Intrinsically Safe and FISCO, Flameproof,
Type n
NEPSI—Intrinsically Safe, Flameproof
Refer to Special Instructions for “Safe Use” and
Installation in Hazardous Locations in section 2,
tables 1-3, 1-4, 1-5, 1-6, and 1-7 and Appendix B
for specific approval information.
Electrical Housing:
CSA—Type 4X, IP66
FM—NEMA 4X
ATEX—IP66
IECEx—NEMA 4X, IP66
NEPSI—IP66
Other Classifications/Certifications
TIIS—Japan
GOST-R—Russian GOST-R
FSETAN—Russian - Federal Service of
Technological, Ecological and Nuclear Inspectorate
INMETRO—Brazil
Contact your Emerson Process Management sales
office for classification/certification specific
information
Connections
Supply Pressure: 1/4 NPT internal and integral
pad for mounting 67CFR regulator
Output Pressure: 1/4 NPT internal
Tubing: 3/8-inch metal, recommended
Vent: 3/8 NPT internal
Electrical: 1/2 NPT internal, M20 adapter optional
Stem/Shaft Travel
Linear Actuators with rated travel between
6.35 mm (0.25 inch) and 606 mm (23.875 inches)
Rotary Actuators with rated travel between 50
degrees and 180 degrees
Mounting
(7)
Designed for direct actuator mounting or remote
pipestand or wall mounting. Mounting the
instrument vertically, with the vent at the bottom of
the assembly, or horizontally, with the vent pointing
down, is recommended to allow drainage of
moisture that may be introduced via the instrument
air supply.
Weight
Valve-Mounted Instruments
Aluminum: 3.5 Kg (7.7 lbs)
Stainless Steel: 7.7 Kg (17 lbs)
Remote-Mounted Instruments
DVC6005f Base Unit: 4.1 Kg (9 lbs)
DVC6015 Feedback Unit: 1.3 Kg (2.9 lbs)
DVC6025 Feedback Unit: 1.4 Kg (3.1 lbs)
DVC6035 Feedback Unit: 0.9 Kg (2.0 lbs)
−continued−
